ISOMETER® isoCHA425HV + AGH420-1/AGH421-1
Abmessungen
36
Maßangabe in mm
Montage
2.
1.
3.
Click!
Montage auf Hutschiene | DIN rail mounting
4
isoCHA425HV_D00404_06_Q_DEEN / 04.2024
Dimensions
93
90
45 70,5
31,1
47,5
74,5
Dimensions in mm
Mounting
&
1 x
2 x
!
Schraubbefestigung | Screw mounting
Anschlussbild
Click
M4
Anschluss an die Versorgungsspannung U
Schmelzsicherung:
Bei Versorgung aus IT-System beide Leitungen absichern.*
Jede Klemme jeweils separat an PE anschließen:
M4
Gleichen Leitungsquerschnitt wie bei „A1", „A2" verwenden.
Anschluss an das zu überwachende IT-Netz
Klemmen des AGH mit den gleichnamigen Klemmen des
ISOMETER®s verbinden.
Anschluss für externe kombinierte Test- und Reset-Taste
Anschluss Alarmrelais „K1"
Anschluss Alarmrelais „K2"
RS-485-Kommunikationsschnittstelle mit zuschaltbarem
Terminierungswiderstand
i
* Für UL- und CSA-Applikationen:
Versorgungsspannung U
5-A-Vorsicherungen zuführen.
i
Für UL-Anwendungen:
Nur 60/75°C-Kupferleitungen verwenden.
ISOMETER® isoCHA425HV + AGH420-1/AGH421-1
Wiring diagram
U
S
6 A
6 A
E
E
Up
Up
KE
A1
A2
AK2
GND
AK1
AK1
GND AK2
k
ON
AL1
AL2
AGH
T
R
MENU
R
on
o
K1
K2
L1/+
L2/–
T/R
14
24
11
Klemme /
Anschlüsse
Terminal
über
s
Connection to the supply voltage U
A1, A2
If supplied from an IT system, protect both lines by a fuse.*
Connect each terminal separately to PE:
E, E, KE
Use same wire cross section as for "A1", "A2".
Connection to the IT system to be monitored
L1/+, L2/–
Connect the terminals of the AGH to the corresponding terminals
Up, AK1, GND, AK2
of the ISOMETER®
Connection for the external combined test and reset button
T/R
11, 14
Connection to alarm relay "K1"
Connection to alarm relay "K2"
11, 24
RS-485 communication interface with selectable
A, B
terminating resistance
i
über
s
i
isoCHA425HV_D00404_06_Q_DEEN / 04.2024
DC+
DC–
PE
Test / Reset
U
> 800 V
n
30 mm
30 mm
AGH
R
COM465IP
A
B
A
B
RS-485
J-Y(St)Y 2x0.6
Connections
via a fuse:
s
* For UL and CSA applications:
Feed the supply voltage U
via 5 A back-up fuses.
s
For UL applications:
Only use 60/75°C copper lines.
5
