IP camera 20-2940A-IP/21-2940A-IP, 20-2941A-IP/21-2941A-IP, 43-2940A, 50-2940A-IP
Important
IP camera may only be operated with cover.
Operation without the camera cover will damage
the camera. When opening the camera cover
for service purposes, only remove the cover
screw and lift off the camera cover carefully.
The camera circuit board and heat sink are
firmly connected to the camera cover. Only very
short connection cable to the camera optics.
Be careful not to scratch, damage or leave
fingerprints on the camera dome, as this may
affect the image quality. If possible, only
remove the protective film after the installation
is complete. Use the cardboard spacers with
hole included with the camera for installation to
avoid damaging the camera dome.
Cover screw
www.behnke-online.de
1.2. General information
1.2.1. Features
The Behnke camera module integrates an
Axis M3086V camera behind an aperture of
the Telecom Behnke modular system series 20,
50 or as reverse side camera 43-2940A.
The camera records videos with a resolution
of up to 2688 x 1512 pixels. Regardless of the
selected resolution, up to 25 images per second
can be transmitted.
The camera may be integrated into standard
video surveillance systems. The camera is
also equipped with LED illumination for use in
poorly lit areas. The video may be transferred
to a video surveillance system via HTTP or via
RSTP streaming. The camera provides an open
interface (VAPIX).
The corresponding documentation is available
from AXIS Communications on their websites.
Various compression methods are available
(see technical specifications)
