Construction

Fig. 1: Construction of the sensor
1 Opening for M12 cable connector
2 Adapter
3 2-lead connection
4 Clamping disc
5 Electrode shaft
36
1
2
3
4
5
6
7
8
9
6 Air vent opening
7 Tubular seal
8 Membrane cap
9 Protective membrane cap
P_DT_0069_SW
