CAUTION: AFTER HAVING PROVIDED POWER TO THE FAN KIT, WAIT A FEW SECONDS BEFORE PRESSING
THE REMOTE CONTROL BUTTONS TO ALLOW THE CHECK-UP OF THE ELECTRONIC BOARDS.
Two types of operations can be selected with the remote control.

•AUTOMATIC OPERATION :

To start the fan in the automatic mode, proceed as follows:
-Light the fire
-press the AUTO button (the number of beeps emitted indicates the speed at which the fan is set)
-set the speed desired pressing the +/- remote control buttons lightly choosing from among four different operating
speeds (V1 – V2 – V3 – V4)
-the fan starts only when the probe detects the turn-on temperature
-the fan will shut-off when the temperature detected by the probe falls below the minimum threshold
-the fan in operation can be turned off at any time clicking the ON/OFF button (the long beep signals the shutting-
down of the system) and it will not start-up even if the probe reaches the start-up temperature
To restart the fan, it's necessary to press the "ON/OFF" or also the "AUTO" button.
If the fan shuts off automatically, it will start again in the same mode if the probe detects a temperature reading greater
than the turn-on threshold.

•MANUAL OPERATION:

To start the fan in the manual operation mode, proceed as follows:
-press the ON/OFF button (the number of beeps emitted indicates the speed at which the fan is set)
-set the speed desired pressing the +/- remote control buttons lightly choosing from among four different operating
speeds (V1 – V2 – V3 – V4)
-the fan starts immediately
-when the temperature detected by the probe exceeds the turn-on value, the type of operation commutes to the
predefined automatic mode and will shut down when the probe reaches the shutdown temperature
-the fan in operation may be shut-off at any time clicking the ON/OFF button (the long beep indicates the shutting
down of the system)

SETTING THE FAN SPEED

Depending upon type of ductwork, two types of speed settings can be chosen:
-SETTING 1, for the fan kit with front or front/rear outlet with a short duct (factory setting for the series);
-SETTING 2, for the fan kit with longer ductwork.
To change from one setting to another, after having turned on the fan in the AUTOMATIC or MANUAL mode, simply
press down on the "ON/OFF" and "-" buttons simultaneously (the acoustical signal in SETTING 2 consists of 2 beeps
followed by the beeps for the speed setting).
Again simultaneously pressing the "ON/OFF" and "-" buttons switches the system to the SETTING 1 mode (the
acoustical signal in SETTING 1 consists of 1 beep followed by the speed setting beeps).
Example:
if we are in SETTING 1 and at SPEED 3 and we hold the "ON/OFF" and "-" buttons pressed simultaneously to pass to
SETTING 2 we will initially hear 2 beeps which identify the new setting (SETTING 2) and then 3 beeps will be heard
which identify the speed setting (in this case SPEED 3).
To return to SETTING 1 simply press the "ON/OFF" and "-" buttons simultaneously again, in this case an initial beep
will be heard (SETTING 1) and then 3 beeps (SPEED 3).
46

7. USE
