COMPACT 1.4
Take care not to invert the polarities when connecting the equipment to the battery. If this happens, the
plate does not come on and the unit does not work.
Blower
Az Blue
N Black
R Red
V Green
B White
A Yellow
Na Orange
M Brown
Compressor
electronic
module

IMPORTANT WARNING!

TEMP
Wiring strip
7.5 A. Fuse
Na
Electronic
module
10 A. Fuse
-
+
+
F
25 A. Fuse
D
C
P
T
Compressor
Air conditioning for vehicles
ºC
ºF
ON/OFF
Battery
21
EN

Electric wiring

Temperature
probe
Fan
Compressor
electronic
module
-
+
+
F
D
C
P
T
Compressor
