Float Installation (Optional) ARF/BNF Basic
1. Assemble the floats following the instructions included with the floats. Use the
mounting positions shown for the strut mounting locations.
2. Use a hobby knife with a #11 blade to expose the slots for the float mounts.
3. Slide the forward mount into the slot. The front float mount can then be inserted
in the slot.
4. Use a drill and 2mm drill bit to drill holes 4mm from the inside edges of the
gear for the straps at the rear.
5. Thread one of the M3 x 10mm self-tapping screws into each hole to cut
threads with a Phillips screwdriver (PH#0), remove the screw.
6. Apply one drop of thin CA glue to each screw hole. Allow the CA to cure, do not
use accelerator. Repeat this process for all mounting locations.
