14. OPTIONS
Specifications
Printing system Direct thermal line head
Max Characters per line 24, 32 or 48
Arial 16, 24 CPL,
Character font Arial 12, 32 CPL
Arial 8, 48 CPL
Average printing speed 10 lines per second (max)
85.5 mm x 150 mm x 55 mm (45 mm low profile
Dimensions
printer)
Weight 400 g approx. (inc batteries and paper)
Internal power supply
4 x 1.2 V NiMH 1600 mAH, AA cells
Paper width
58 mm
Paper capacity 25 m (std printer),10 m (low profile printer)
Interface
Data format RS232C
Connector
6-way RJ12 socket
Above specifications may change without notice from supplier.
Please ask for technical specifications before purchase. For further
information and technical support please contact your local distributor.
28
14. OPTIONS
14.2 Scanner
®
The HemoCue HbA1c 501 Analyzer accepts data input from the following
barcode standards
Code 93 standard including check digit
Code 39 with optional check digit required
Code 128 standard including check digit
CodaBar without check digit
Activate use of barcoding system by a pre-set process (page 9).
The barcode scanner can be used to scan patient ID and operator ID.
Scanned information is stored in the analyzer for future reference.
On/Off 9V USB Barcod Printer
When performing test using barcode system
®
STEP 1. Open the lid of HemoCue
HbA1c 501 analyzer
STEP 2. Insert the cartridge when
'Cartridge insert' is displayed.
STEP 3. The display shows 'Patient ID'
and 'Operator ID' .
STEP 4. Scan the Patient ID barcode. STEP 5. Scan the Operator ID barcode.
