Checking Vario-
Star 2500 CSA/
3100 CSA mains
voltage
(continued)
Fig.9 Control transformer terminal board (CSA
machines)
3. Compare connecting terminal plate
and printed connection diagram for
the control transformer. The cable
marked with a cable tie must be
connected according to the mains
voltage
4. Attach the right side panel to the
power source
11
