Start-up
Incorrect installation also means that
you are running the risk of serious
damage to property, e.g. from fire. You
risk personal liability for personal injury
and property damage.
Consult an electrician!
*Specialist knowledge required for ins-
tallation:
The following specialist knowledge is
particularly important during installati-
on:
• The "5 safety rules" to be
used:disconnect from mains; sa-
feguard from switching on again;
check that no voltage is present
in system; earth and short circuit;
cover or cordon off neighbouring
live parts;
• Select suitable tool, measuring
equipment and, if necessary, per-
sonal safety equipment;
• Evaluation of measuring results;
• Selection of electrical installation
material for safeguarding shut-off
conditions;
• IP protection types;
• Installation of electrical installation
material;
• Type of supply network (TN sys-
tem, IT system, TT system) and the
resulting connecting conditions
(classical zero balancing, protective
earthing, required additional mea-
sures etc.).
6.2.4 Installation in multiple
combinations
You can mount the wall thermostat
with the attachment frame (A) provided
or use it with frames of other manu-
facturers as well as integrate the elec-
tronic unit (B) into a multi-gang frame.
You can flexibly fix the mounting plate
(F) to the wall using adhesive strips
or screws. For mounting with multi-
ple combinations, make sure that the
mounting plate of the wall thermostat
is seamlessly aligned to the already
fixed mounting plate/retaining ring.
The wall thermostat is designed to fit
into frames supplied by the following
manufacturers:
Manufacturer Frame
Berker S.1, B.1, B.3, B.7 glass
ELSO Joy
System 55, Standard
GIRA 55, E2, E22, Event,
Esprit
1-M, Atelier-M,
merten M-Smart, M-Arc,
M-Star, M-Plan
A 500, AS 500, A plus,
JUNG
A creation
33
