INSTALLATION IN THE VEHICLE

!!! Please do not Ieave your child unattended in the child safety seat in
the vehicle.
!!! For the protection of all vehlcle occupants
ln the case of an emergency stop or an accident unsecured persons or objects
may cause injury to other vehicle occupants. Please always check that:
The backrests of the vehicle seats are locked (i.e.that a foldable rear seat bench latch
•
is engaged).
AII heavy or sharp-edged objects in the vehicle (e.g.on the parcel shelf) are secured.
•
AlI persons in the vehicle have their seat belts fastened.
•
The child safety seat is always secured when it is in the vehicle, even if no child is
•
being transported.
To protect your vehicle
Some vehicle seat covers of sensitive materials (e.g.velour, leather, etc.) may develop wear
marks when child seats are used.This can be avoided by placing a blanket or towel under
the child seat.
INSTALLATION OF 76-105CM
ISOFIX+TOP TETHER+HARNESS
First please check if there are 2 SOFIX anchorages in the perpendicular intersection of
the vehicle seat back and seat cushion, and the user-ready tether anchorage behind
the vehicle seat.
Tips: The user-ready tether anchorage usually permanently installed on the inner rear
luqqage shelf or on the vehicle floor. Details you could read your vehicle quidelines or
contact the vehicle manufacturer.
1.
38
Press the ISOFIX release button and push the ISOFIX
connectors forward as far as possible.
2.
Push the lSOFIX connectors
directly into the ancho-
rages until heard an audible
sound "click".
3.
Grasp the seat body to check the seat if it is fastened
tightly or shakes. If the seat shakes and the ISOFIX
connectors are pulled out, please repeat the above steps
and install it again.
4.
Pull out the top tether and
press the tether strap re-
lease button to extend the strap
until it is long enough to hook
the user-ready tether anchorage
behind.
6.
Pull the tether strap on anot-
her end back to tiqhten the
top tether.
CAUTION: lf the top tether is
tightened favorably and correctly, a
green mark will turn up on the other
end of the strap release button,
please do check it.
FREEFIX I-SIZE
DE
EN
FR
NL
5.
Hook the tether strap hook
onto the user-ready ancho-
rages. Check there maybe are 3
anchorages for the hook, please
find one in your favor.
39
