INSTALLATION OF 100-150CM
ISOFIX+ADULT SAFETY-BELT OR ADULT
SAFETY-BELT ONLY
,
Before the installation, please store the Harness system
of baby car seat.
Note: The Baby insert, Harness strap, Harness buckle,
Buckle pads& Shoulder pads should be stored away
safely for future use
Do not to use any load bearing contact points other than those described in the ins-
tructions and marked in the child restraint. The belt must be routed as shown ln the
instructlons.
40
1.
Adjust the height of the
headrest to suit your
child.
ISOFIX connector is optional,
you can ignore this step if
you do not want to use it.
2.
Put the shoulder belt
through the shoulder.
3.
Place your child on the
car seat and pass the
belts through the red waist belt
Click
guide. Fasten the car belt with
an audible sound"click".
4.
Make sure the Lap belt
is stretched as low as
，
possible over the child's hips ,
and fastened into the buckle .
The shoulder belt must cross
midway between child's shoul-
der and neck.
REMOVE THE BABY CAR SEAT
REMOVE FROM TOP TETHER
REMOVE FROM ISOFIX
，
1.
Press the lSOFIX unlock button on the green indicator and simultaneously press the
button to remove it from the ISOFIX anchor points.
，
2.
，
Do this for both sides.
3.
If the ISOFIX mount does not unlock. push the car seat a little further to the back of
the bench to more easily disengage the mountings.
，
，
，
FREEFIX I-SIZE
1.
Pull out the top tether
and press the tether
strap release button to extend
the strap
2.
Remove the tether strap
hook from the user-
ready anchorages.
，
DE
EN
FR
NL
41
