PART REPLACEMENT

To carry out this operation, proceed as follows.
Close the gas supply tap.
1)
Open the hatch (A).
2)
Undo the locking screw (B).
3)
Set the bushing (C) at the distance shown in
4)
the table.
Tighten the screw (B). After making the ad-
5)
justment, seal the screw with paint.
Close the hatch (A) once the operation is com-
6)
plete.

INSTRUCTIONS AND WARNINGS FOR PART REPLACEMENT

NOTE
: Read the following section of
the "user instruction manual" carefully be-
fore replacing any part:
– Hazards and safety provisions during instal-
lation and commissioning, adjustments and
part replacement.
WARNING: Before carrying out
any replacement procedure, activate all
the safety devices provided and decide
whether staff at work and those in the
vicinity should be properly informed.
In particular, close the gas supply tap
and prevent access to all devices which
might cause unexpected hazards and
damage to people's health and safety if
activated.
3413780_inst_GB

ADJUSTING THE BURNER PRIMARY AIR

PART REPLACEMENT
A
When replacing worn parts, use original
spare parts only. The manufacturer declines
all responsibility for injury or damage to
components resulting from the use of non
original parts, or extraordinary work on the
appliance which may modify the safety re-
quirements without the Manufacturer's au-
thorisation. When ordering components,
follow the instructions provided in the spare
part catalogue.
ENGLISH
B
C
15
