Note:
In accordance with the applicable product liability laws,
the manufacturer of this product assumes no liability for
damage to the product or caused by the product arising
from:
• Improper handling
• Non-compliance with the operating manual
• Repairs carried out by third parties, unauthorised spe-
cialists
• Installing and replacing non-original spare parts
• Improper use
Note:
The operating manual is part of this product.
It includes important instructions for the safe, proper and
economic operation of the product, for avoiding danger,
for minimising repair costs and downtimes and for in-
creasing the reliability and extending the service life of the
product. In addition to the safety instructions in this oper-
ating manual, you must also observe the regulations ap-
plicable to the operation of the product in your country.
Familiarise yourself with all operating and safety instruc-
tions before using the product. Only operate the product as
described and for the specified areas of application. Keep
the operating manual in a good place and hand over all
documents when passing the product on to third parties.
2
Product description (Fig. 1-6)
1.
Switch lock
2.
Rear handle
3.
Battery mount
4.
On/off switch
5.
Locking nut (tool attachment)
6.
Locking mechanism
7.
Telescopic tube
8.
Front handle
9.
Carrying eye
10.
Lock button (tilt adjustment)
11.
Tool attachment (hedge trimmer)
12.
Cutter bar
13.
Blade guard
14.
Tool attachment (pole-mounted pruner)
15.
Oil tank
16.
Chainsaw guide bar (guide rail)
17.
Saw chain
18.
Chain tensioning wheel
19.
Guide bar and chain guard
20.
Shoulder strap
21.
Chain cover
22.
Chain wheel
23.
Guide pin
24.
Stud bolts
25.
Oil level indicator
26.
Release button (battery)
27.
Battery*
* = not included in the scope of delivery!
3
Scope of delivery (Fig. 1)
Item
Quanti-
Designation
ty
11.
1 x
Tool attachment (hedge trimmer)
13.
1 x
Blade guard
14.
1 x
Tool attachment (pole-mounted pruner)
16.
1 x
17.
1 x
19.
1 x
20.
1 x
1 x
1 x
4
Proper use
The product may only be fitted to the motor head sup-
plied.
Brushcutter:
The strimmer (using the cutting knife) is suitable for cut-
ting shrubs, strong weed and undergrowth.
Grass trimmer:
The grass trimmer (using thread coil with trimming line) is
suitable for cutting lawns, grass areas and light weed.
Hedge trimmer:
This hedge trimmer is intended for cutting hedges, bush-
es and shrubs.
Pole-mounted pruner (chainsaw with telescopic
handle):
The pole-mounted pruner is intended for branch removal
work. It is not suitable for extensive sawing work and fell-
ing trees as well as sawing materials other than wood.
The product may only be used in the intended manner.
Any use beyond this is improper. The user/operator, not
the manufacturer, is responsible for damages or injuries
of any type resulting from this.
An element of the intended use is also the observance of
the safety instructions, as well as the assembly instruc-
tions and operating information in the operating manual.
Persons who operate and maintain the product must be
familiar with the manual and must be informed about po-
tential dangers.
The liability of the manufacturer and resulting damages
are excluded in the event of modifications of the product.
The product may only be operated with original parts and
original accessories from the manufacturer.
The safety, operating and maintenance specifications of
the manufacturer, as well as the dimensions specified in
the technical data, must be observed.
Please note that our products were not designed with the
intention of use for commercial or industrial purposes. We
assume no guarantee if the product is used in commercial
or industrial applications, or for equivalent work.
Explanation of the signal words in
the operating manual
DANGER
Signal word to indicate an imminently haz-
ardous situation which, if not avoided, will re-
sult in death or serious injury.
WARNING
Signal word to indicate a potentially hazard-
ous situation which, if not avoided, could re-
sult in death or serious injury.
www.scheppach.com
Chainsaw guide bar (guide rail)
Saw chain
Guide bar and chain guard
Shoulder strap
Cordless multi-function device
Operating manual
