TIPP.
•
You can copy trigger settings to search for other locations in your acquired waveform that meet the trigger conditions.
•
You can also copy search settings to your trigger.
•
Custom (User) marks are saved with the waveform when the waveform is saved and when the setup is saved.
•
Automatic search marks are not saved with the waveform when the waveform is saved. However, you can easily recapture
them by reusing the search function.
•
The search criteria are saved in the saved setup.
The Wave Inspector includes the following search capabilities:
Search
Edge
Pulse Width
Timeout
Runt
Logic
Setup & Hold
Rise/Fall time
Benutzerhandbuch für die Oszilloskop-Baureihe MDO4000C
Description
Searches for edges (rising, falling or both) with a user-specified threshold level.
Searches for positive or negative pulse widths that are >, <, =, or ≠ a user specified pulse width,
or are inside or outside of a range.
Searches for the lack of a pulse. The signal stays above or below (or either above or below) a
set value for a set amount of time.
Searches for positive or negative pulses that cross one amplitude threshold but fail to cross a
second threshold before crossing the first again. Search for all runt pulses or only those with a
duration >, <, =, or ≠ a user specified time.
Search for a logic pattern (AND, OR, NAND, or NOR) across multiple waveforms with each
input set to either High, Low, or Don't Care. Search for when the event goes true, goes false, or
stays valid for >, <, =, or ≠ a user specified time. Additionally, you can define one of the inputs
as a clock for synchronous (state) searches.
Setup & Hold Search for violations of user specified Setup and Hold times.
Search for rising and/or falling edges that are >, <, =, or ≠ a user specified time.
Analyse von Signal- oder Strahldaten
151
