Camera Settings

10
Camera Settings
Supported Video Formats
1920 x 1080p23.98
1920 x 1080p24
1920 x 1080p25
1920 x 1080p29.97
1920 x 1080p30
1920 x 1080p50
1920 x 1080p59.94
1920 x 1080p60
1920 x 1080i50
1920 x 1080i59.94
1920 x 1080i60
Studio Camera Settings
Camera Settings
To configure settings on your Blackmagic Studio camera, press the MENU button.
Use the navigation buttons to highlight menus and use the SET button to confirm your selection.
Video Format
Select the video format you wish to output. A list of supported formats is on the left of the page.
Gain
Gain settings are helpful when you are shooting in low light conditions. The default setting is 0dB and gain
can be increased in 3dB increments up to +9dB.
White Balance
Six white balance presets are selectable for a variety of color temperature conditions.
‚ 3200K for tungsten light
‚ 4500K for fluorescent light
‚ 5000K, 5600K, 6500K and 7500K for a variety of daylight conditions such as time of day.
Shutter Speed
Shutter Speed complements the ISO setting by regulating the amount of light on the sensor. There are 15
different shutter speeds available ranging from 1/50 sec to 1/2000 sec.
Dynamic Range
Film
The film setting shoots video using a log curve and gives you 13 stops of dynamic range.
The film dynamic range setting maximizes the information in your video signal to help you get the most
out of color grading software, such as DaVinci Resolve.
Video
The video setting uses the REC709 standard for high definition video which is compatible with modern
studio equipment.
Language
English is the default language. Additional languages including: Japanese, French, German, Russian,
Spanish, Chinese and Korean will be supported in the future.
