Technical data

Property
Backset
Centres distance
Handle follower
Rebate gap in variants for:
· single-leaf doors
· double-leaf doors
Bolt throw
Face plate
· Width
· Height
· Thickness
Material
· Lock case
· Bolt
· Latch
· Face plate
Rigidity/protection
Deadbolt counterforce Deadbolt
transverse shear stress
Installation position
Operating temperature
Corrosion resistance
Rated operating voltage, regulated
Rated current consumption
· Locked in idle state
· Motor coupling active
(engage / disengage)

Updated information

Updated information, such as reports on current fire testing, can be found online
at: www.assabloy.de
35 mm, 40 mm, 45 mm,
55 mm, 65 mm, 80 mm
92 mm
9 mm
2 mm – 6 mm
4 mm – 8 mm
20 mm
809N 819N
24 mm 24 mm
446 mm 1760 mm
6 mm 6 mm
Stainless steel / Zinc diecast
Steel 60 HRC (hardened surface)
Steel
Steel, chrome-plated
6,000 N
20,000 N
Vertical
–10°C – +60°C
high corrosion resistance (96 h)
12 V – 24 V DC ± 15 %
50 mA
80 mA
