Output
(from the standard
I/O 2 connecting
plug to the fieldbus
coupler)
+24 V
GND
A09
A10
A11
A12
A13
A14
A15
A16
Input signals for Robacta TC 1000, Robacta TC 2000:
Input
(from the fieldbus
coupler to the stan-
dard I/O 2 connec-
ting plug)
E09
E10
E11
E12
E13
E14
E15
E16
Output signals for Robacta TC 1000, Robacta TC 2000:
Output
(from the standard
I/O 2 connecting
plug to the fieldbus
coupler)
+24 V
GND
A09
A10
A11
A12
A13
44
Pin on the
standard I/O 2
connecting
plug Signal
1 -
2 -
3 Start cleaning
4 Spray parting agent
5 Cut the wire electrode
6 Actuator output signal
7 GND for the sensors
8 Reserve
9 Reserve
10 Reserve
Pin on the
standard I/O 2
connecting
plug Signal
11 Ready
12 Fluid Level Control
13 Cleaning Error
14 Reserve
15 Reserve
16 Reserve
17 Reserve
18 Reserve
Pin on the
standard I/O 2
connecting
plug Signal
1 -
2 -
3 Cleaning Start
4 Spray In
5 Wire Cutter
6 Quick Stop
7 Reserve
Action
-
-
High
High
High
High
High
-
-
-
Action
High
High
High
-
-
-
-
-
Action
-
-
High
High
High
High
-
