Interface con-
nections - TS/
TPS, MW/TT ran-
ge
Interface connections
For your infor- IMPORTANT! While the robot interface is connected to the LocalNet, „2-step
mation mode" remains selected (display: 2-step mode).
Further information on the „special 2-step mode for robot interface" can be
found in the sections headed „MIG/MAG welding" and „Mode welding parame-
ters" in the power source operating instructions.
Application ex-
ample - TS/TPS,
MW/TT range
(1)
(2)
(3)
(4)
(5)
(2)
(2)
(1) (10) (9)
Power source
DeviceNet
Interconnecting hosepack
Wire-feed unit
Welding torch
(1) Strain-relief device with cable
glands
for the DeviceNet data line and
the power supply for the field
bus coupler
(2) LocalNet connection
for connecting the interconnec-
ting hosepack
(1)
(4)
(3)
(8) (7) (6)
(6) Robot
(7) Welding wire drum
(8) Robot control
(9) DeviceNet data cable
(10) Cooling unit
(5)
