2. Scope of delivery

The following parts can be found in packaging. Ensure that all the parts are intact.
•
Manual
•
Generator unit
•
Tool
•
2 x bottom rollers assembled
•
2 x guide rollers assembled
•
Battery incl.
Depending on the purpose of the application, additional accessories may be necessary
Hint: If possible, keep the packing until the warranty period has expired.

3. Technical Data

Modell
Protection type
Frequency F (Hz)
rated
Rated voltage U (V)
rated
Continuous power rating P
rated
Max. Power P
max
Rated current I (A)
rated
Rated voltage DC
Rated current DC
Quantity and type of sockets
Motor typ
Engine approval number
Capacity (cm³)
Max. power (kW / PS)
Fuel type
Power factor cos φ
Power class
Max. ambient temperatue
Max. installation height (above normal null) (m)
Guaranteed sound power level
Oil quantity
Recommended oil specification
Tank content
Running period with 1/2 load
Dimension of device: l x b x h (mm)
Weight (net)
Item no.
Information about noise emission
Measurement readings ascertained as per EN 3744:
Sound power level measured L
Sound power level guaranteed L
The values specified are emission levels and are not necessarily safe work levels. As there is a relation between
the emission and immission levels, it cannot be reliably used for determining the necessary additional precaution-
ary measures.
18
(kW)
: 96 dB(A), Uncertainty K = 2 dB
WA
: 97 dB(A)
WA
Translation of the Original Operating Instructions
CPG 6000 DEV
IP23M
50 Hz
230 VAC 1P / 400 VAC 3P
3 kW / 4,2 kW
3,3 kW / 5,0 kW
13 A / 7,6 A
12 V
8,3 A
2*230 V~ / 1*400 V~ / 1*12 V DC
HP 186FA
e49*2016/1628*2018/989EC1/D*1002*00 (V)
418 cm³
6,3 kW / 8,6 PS
Diesel
1,0 (1P) / 0,8 (3P)
G1
40 °C
1000 m üNN
97 dB (A)
1,65 Liter
SAE 10 W 30
15 Liter
10,5 Std.
915 x 525 x 770
ca. 150 kg
68034
