COMPACT 3.0
EN
Detailed instructions on the installation of power supply cables
Connect the power cable to the unit's cable
1
clamp and pass the cabling behind the input
pipe.
Take down the cabin and pass the cable
2
through the indicated place to the positive
connection point on the front of the cabin.
2
1
2
26
2
2
®
1
