dirna Bergstrom bycool green line COMPACT 3.0 Montageanweisungen Seite 25

COMPACT 3.0
M8 x70 x 100
/ 120 stud
15 or 25 mm rubber joint
according to height of cabin
nerve
Cabin roof
Upholstery
Exploded side view to supports fastening
Exploded rear view to consoles fastening
Ø 6 rubber washer
Ø 6 wide ring flat washer
M6 nut
Interior air distribution panel
Original screw
M6 nut
25
ø 7 rubber washer
ø 8 wide ring flat washer
M8 nut
M8 nut
ø 8 wide ring flat washer
Fastening support
Wide ring flat washer
M8 selfblocking nut
M6 stud
Console
EN
®
