COMPACT 3.0
EN
HOW TO CUT EPDM GASKET TO
!
AVOID WATER FILTRATION INTO
A- Glue gasket, keeping 100 mm of protection
paper at each side.
B- Remove the two pieces of paper.
C- Glue by pressing both ends.
B
Gasket
CABIN EXTERIOR:
3
Position the Compact in the gap.
Caution! When positioning the unit above
the hatch gap, check that the wastewater
run-offs are not blocked by the EPDM
seal.
THE CABIN
Gasket
Remove
A
Gasket
100 mm Approx. (protection paper)
C
Gasket
18
®
15 mm
Gasket
Cabin roof
Gasket
3
Sun hatch
