en 80 | FALCO EVO 620 S (IT) | Technical specifications
9.

Technical specifications

9.1 FALCO EVO 620 S (IT)
Function
Unseating unit force
Air supply pressure
Supply voltage
9.2 Temperature and working
environment
Function
Working temperature
Storage Temperature
Temperature gradient
Humidity
Humidity gradient
Maximum operating height
Max. transportation height
9.3

Working range

9.3.1 Passenger car tires
Function
Rim width
Maximum tire diameter
Rim diameter
(clamping the rim on the inside)
Rim diameter
(clamping the rim on the outside)
|
1 695 108 846 2018-07-01
9.3.2
Function
Rim width
Max. tire diameter
Specifications
motorcycle/scooter
11,5 kN "
Rim diameter
8 – 10 bar
depending
i
on the voltage ordered
(see rating
plate)
(1)
Specifications
-5° C \ +40° C'
-20° C \ + 60° C
20° C
10% \ 90% (40° C)
10%
-200 mt. \ 3.000 mt.
-200 mt. \ 12.000 mt.
min / max
(2)
3 - 11 inch
1100 mm
12 - 24 inch
10 - 22 inch
Fig. 93:
Fig. 94:
Motorcycle/scooter tires
In order to work with motorcycle tires, motorcycle tire
adapters have to be installed. Available on request
(special accessory).
Max 10 N*m
Max 10 N*m
652176-21_BM
Mounting accessories for motorcycles and scooters
Mounting without a spacer plate 10 - 22 inch
min / max
3 - 10 inch
1100 mm
7 - 23 inch
