en 64 | FALCO EVO 620 S (IT) | Initial Operation
4.5

Checking the direction of rotation

!
For proper operation of the FALCO EVO 620 S (IT), it
is essential that the clamping flange starts to rotate
clockwise the pedal shown in the illustration is
pressed down.
!
If the direction of rotation is counterclockwise, seek
the aid of a qualified electrician or appropriately
trained individual.
Fig. 61: Checking the direction of rotation
i
The machine version with drive motor is equipped
with a rim-chuck plate with double rotational speed.
The illustration shows the utilization.
The machine version with AC motor is equipped with
a rim-chuck plate with a single rotational speed.
|
1 695 108 846 2018-07-01
4.6 Fitting plastic protective covers
!
The plastic protective covers should be fitted to
protect the rim from damage during operations.
4.6.1 Guide rail guards
652211-42_BM
Fig. 62: Fitting guards for rails
