4. Attach the fixing bracket(s) (depending on the model) to the heater's lower rear heater,
using 2 screws (C) for each bracket as shown in Figure 9.
5. Hang the heater from the 2 hooks (C) on the wall as shown in Figure 10. Make sure the
heater is securely attached to both hooks.
6. Once the heater is hung in position, make 2 marks on the wall where the 2 brackets (A)
must be attached to fix the bottom of the heater to the wall. Fig. 11
7. Remove the heater and drill 2 holes of 4-mm diameter, with a minimum depth of 25 mm,
on the 2 wall marks.
8. Insert the 2 plugs to secure them with 2 screws (B) and securely fix the heater to the wall.
Fig. 12
Floor assembly
Assembling the feet
Screw the 2 feet to the heater's bottom rear with 4 screws (F), 2 screws per foot.
Fig. 13
4. OPERATION
- Place the device on a flat, stable surface.
- Turn it on by the side switch after plugging it to a power socket. The device will beep.
- Press the On/Off button. The LED display will show the room temperature.
- Use the control panel or the remote control to select the power, temperature, and operating
time.
- The device will beep every time you press a button.
Touch control panel Fig. 14
1. LED display
2. Wi-Fi-signal icon
3. On/Off button
4. Temperature button
5. Mode button
6. Timer button
Note
The Wi-Fi-signal icon has no function. To activate the Wi-Fi function, press and hold the
temperature button for 5 seconds.
Turning the device on and off
Press the On/Off button on the display or remote control to switch the device on or off. When
READY WARM 800 /1200 / 1800 / 2000 / 2500 THERMAL CONNECTED
ENGLISH
57
