ENGLISH
3. PRODUCT INSTALLATION
The device can be installed either on the floor or on the wall (feet and mounting brackets
included).
Note
- Never install the appliance directly under a wall socket.
- Never install the appliance in a place or position where it can be reached from the bath or
shower.
- The heater operates on natural-air convection. For optimum performance and even heat
distribution, when installing the heater on the wall, the bottom should be at least 20 cm
from the floor, 20 cm clearance to the sides, 50 cm clearance on the top, and 20 cm from
any walls or objects (furniture, curtains, etc.). Fig. 3-4
Wall assembly
- Choose a suitable spot on the wall; it should be steady and level. Check that there is a
power socket nearby.
- The distances marked "a" and "e" will depend on the heater's model.
Fig. 5-6
Table 1. Reference distances by model for installation:
Reference: Models
Ready Warm 800 Thermal
05372
Connected
Ready Warm 1200
05373
Thermal Connected
Ready Warm 1800
05374
Thermal Connected
Ready Warm 2000
05375
Thermal Connected
Ready Warm 2500
05376
Thermal Connected
1. Always follow the above safety measures (Fig. 5-6). Make 2 marks on the wall according to
the "e" measurement indicated in Table 1 and at 695 mm from the floor. Fig. 7
2. Drill 2 holes of 10-mm diameter with a minimum depth of 60 mm on the markings.
3. Insert the 2 plugs (D) into the 2 holes and fix the 2 hooks (C) with 2 screws (D) to the wall
as shown in Figure 8.
56
READY WARM 800 /1200 / 1800 / 2000 / 2500 THERMAL CONNECTED
A (mm) B (mm) E (mm)
410 93 140
550 93 280
690 93 420
830 93 560
970 93 700
F (mm)
495
495
495
495
495
