FXR-A01
Anbauanleitung/Manual
3 Quickshifter
4 Quickshifter
M6-934
M6x30-913
M6-934
USW14
M6-934-L
-Gewindestift M6x30-913 an Schaltassisten min. 6
mm einschrauben und mit Kontermutter
M6-934 sichern(3).
Anzugsdrehmoment: 10 Nm
Schalltwelle USW14 einsetzen, Schalthebelhöhe
einstellen und mit Kontermuttern M6-934 / -L
sichern(4).
Anzugsdrehmoment: 10 Nm
-Install threaded bar M6-913 a min. of 6mm into
quick shifter and secure with nut M6-934(3).
Tightening torque: 10 Nm
-Insert gear shift rod USW 14, adjust gear lever
height and secure with nuts M6-934 / -L. One uni-ball
is left-hand thread(4).
Eine Schaltumkehrung mit Serienschalt-
assistent ist nicht möglich.
It is not possible to install GP-shifting with
the OEM quick shifter.
