Technical Specifications - Ground Zero GZDSP 6-8X Anleitung

Model
Type
Frequency Response
Signal to noise ratio
Channel separation
Harmonic distortion
Processor
Input sensitivity
Input impedance
Output
Input
Remote out
Recomended fusing
Dimensions (heatsink)
W x H x L mm / inch
Dimensions (total)
W x H x L mm / inch
Software compatibility
Presets
Gain bandwith
Equalizer
Time alignment
Crossover
Phase switch
Optional remote control
(GZDSP Remote)

Technical Specifications

Cirrus Logic Single Core 32 bit, 8 channel, 192 kHz
Main: 6 x RCA audio socket / 6 x high-level
Aux: 3.5 mm / 1/8" stereo jack
Digital: TOSLINK optical 12 - 96 kHz stereo
96 x 39 x 185 / 3.78" x 1.54" x 7.28"
132 x 42 x 185 / 5.2" x 1.65" x 7.28"
Microsoft Windows™ XP SP3, Vista, 7, 8, 8.1,10
10 Individual presets – storing/calling via optional remote control GZDSP Remote
6 x 31 bands on each channel (A-F) (20-20000Hz) -18 to +12dB, Q 0.5 - 9
2 x 11 bands on subwoofer channels (G/H) (20-200Hz), -18 to +12dB, Q 0.5 - 9
0 - 15ms / 0 - 502cm per channel
6 / 12 / 18 / 24 / 30 / 36 / 42 / 48 dB/Oct. BPF / LPF / HPF Butterworth
selectable (0˚ / 180°) per channel
- 20 -
GZDSP 6-8X
8 channel DSP unit
5 Hz – 20 KHz
(-3 dB)
>110 dB
>60 dB
0.05%
High level: 2 – 15 V RMS
Low level: 0.6 – 5 V RMS
Aux inpu: 0.6 – 5 V RMS
>47 kOhm
8 x RCA audio socket
Max 130mA
2 A
-40 ~ + 12dB
20 - 20000Hz
Main level, subwoofer level,
input mode, preset selection
