1
Input Set
2
Level Controller
3
LED Display
4
Mode (Presets)
In order to install and use the PC software, a Windows™ XP (SP3) operating system (or later) and a USB port is required.
The installation will need about 25 MB free memory space. We recommend to use a laptop for easier handling.
Insert the enclosed CD-ROM into the CD drive of your PC. If there is no CD drive available, the software can be
downloaded from the following link:
Run the setup.exe, the installation wizard will install the software for the DSP the usual way. We recommend to create a
desktop icon. The drivers will be installed automatically during the DSP software installation. Restart the PC after the
installation has been finished.
Important note for 64 bit operating systems:
It may be necessary to install a 64 bit driver manually. The driver can be found on the CD-ROM or at:
http://ground-zero-audio.com/de/downloads/dsp-software.html
Software update:
Please note that you should always use the latest DSP-Software. Here you can download all software versions:
http://ground-zero-audio.com/de/downloads/dsp-software.html
Remote Control Unit Features (optionally available)
1
2
Selects the Input Mode in shown sequence (MAIN/AUX-IN/OPTICAL)
The controller sets the main volume level of the DSP unit. Subwoofer level (SUB OUT G/H) can be
adjusted after pushing and holding the button for approximately 3 seconds.
The LED display will show the current volume level or the chosen preset
Up/Down button switch between previously saved presets. The OK button confirms the selection and
sets the DSP to this preset.
Installation of PC software
http://ground-zero-audio.com/de/downloads/dsp-software.html
3
- 7 -
4
