4
GAIN & DELAY
5
SPEAKER DISTANCE
Channel configuration
Select – Marking the Select-box allows to group the respective
channels together for combined adjustments of Gain and Delay.
Gain – Adjusting the output level of the respective channel
Delay(ms) – Adjusting the time alignment of the respective
channel. Displayed in milliseconds.
It is recommended to fill-in the measured distances of the
speakers to the listening position first (5) and realize the fine-
tuning afterwards at Delay(ms)
Phase – 0 / 180° Phase inversion of the respective channel
– Mute of the respective channel
Speaker distance entry
Before realizing the fine-tuning of each speakers time
alignment in window 4 Delay(ms) , the measured distances
of all connected speakers should be added to the graphic.
The distances can be measured with an usual measuring
tape.
The exact distance between listening position (head) and
cone center of each speaker must be measured.
The explanation of a correct implementation on the
following page can be used as an application example.
- 14 -
