DIGITAL SOUND
PROCESSOR
•
Digital sound processor
•
Simple handling via 1-page user interface
• Realtime setup (all functions)
• Cirrus Logic single core 32 Bit, 8-channel, 192 kHz
•
6 channel input / 8 channel output
•
High-level and low-level input
•
DC Auto-On (using the high-level input)
•
TOSLINK input (optical @12 ~ 96 kHz )
•
3.5mm stereo jack AUX – input connector
•
6 x 31 band equalizer ( -18 to + 12 dB / Q: 0.5 - 9 ) 20 - 20000 Hz (on output A - F)
• 2 x 11 band equalizer ( -18 to + 12 dB / Q: 0.5 - 9 ) 20 - 200 Hz (on output G/H)
•
Time alignment – adjustable range 0 - 15 ms / 0 - 510 cm
•
Adjustable filters (Butterworth) HPF / LPF / BPF with a slope of 6 – 48 dB/Oct.
•
selectable phase shift for each channel (0˚ or 180°)
•
Memory for up to 10 user presets
•
Optional remote control unit with LED display to adjust the main volume and
switch between the presets and input mode
MANUAL
GZDSP 6-8X
Features
