Removing car seat from AXKID ENVIROBASE
8
To release the car seat from AXKID ENVIROBASE, pull the seat release handle (E) and lift the car seat straight up at the same time.
Removing AXKID ENVIROBASE from
your vehicle
9
Release tension on the support leg (M) by pulling the support leg knob (K) and retract the support leg to its shortest position.
Release tension on the front brace (A) by pulling the front brace release knob (B) and adjust the front brace to its shortest position
10
by pushing the front brace into the envirobase.
Press in and slide backwards on the ISOFIX release buttons (H) to release the AXKID ENVIROBASE from the vehicle. Repeat this
11
step on both sides. The envirobase should now be released and free to remove from the vehicle.
The support leg (M) can be folded away into it' s parking position (L) when AXKID ENVIROBASE is outside of the vehicle for easy
12
handling and storage (see F4). WARNING: Never use AXKID ENVIROBASE in the vehicle with the support leg in the parking
position. The supprt leg is an important safety feature and must always be used in the vehicle.
AXKID ENVIROBASE adjustments
The AXKID ENVIROBASE can be adjusted to provide more leg space for the child or to provide more space for the driver or passenger
seat in your vehicle. This is done by adjusting the length of the ISOFIX arms and the front brace.
The ISOFIX arms (F) can be adjusted to different lengths to accommodate different seating positions. There are 4 positions, i-iv.
F1
The ISOFIX arms (F) are adjusted by pulling the ISOFIX knob (I) and simultaneously pushing or pulling on the ISOFIX arms (F).
The front brace can be adjusted to different positions to accommodate different seating positions with more or less leg room for
F2
the child. The front brace (A) is not installed on the base at delivery and must be inserted into AXKID ENVIROBASE. Pull the front
brace release knob (B)and slide the front brace (A) into its slot. Make sure that the front brace release knob (B) clicks into position
after adjusting the front brace. WARNING: The front brace is an important safety feature and must always be used when installing
AXKID ENVIROBASE in a vehicle.
If no sound is emitted from the support leg installation buzzer (O) when the support leg is folded out, check the battery. The battery
F3
is checked by unscrewing the two screws under the support leg foot (N) and removing the cover. The battery is then accessible.
Note that you can only replace the battery with a CR1632 size battery.
The support leg (M) can be folded into a parking position by pulling downwards on the support leg and fold it underneath AXKID
F4
ENVIROBASE and push it into the parking position. The parking position allows for easier handling and storage of AXKID
ENVIROBASE and also stops the support leg installation buzzer (O) from beeping when the AXKID ENVIROBASE is not in use.
The parking position of the support leg should only be used outside of the vehicle. The support leg is an important safety feature
and must always be used when installing enviro base in a vehicle.
