Axkid ENVIROBASE Bedienungsanleitung Seite 12

Parts
A
F
G H I
L
M
N
O
B C
12
D E
A FRONT BRACE
B FRONT BRACE RELEASE KNOB
C
ATTACHMENT HOOKS
D
SEAT ATTACHMENT INDICATOR
E SEAT RELEASE HANDLE
F ISOFIX ARM
G ISOFIX INSTALLATION INDICATOR
H ISOFIX RELEASE BUTTON
I
ISOFIX KNOB
J
SUPPORT LEG INSTALLATION
INDICATOR
K
SUPPORT LEG KNOB
L
SUPPORT LEG PARKING POSITION
M SUPPORT LEG
N SUPPORT LEG FOOT
O SUPPORT LEG INSTALLATION
BUZZER
J
K
