Table of Contents
1.0 Tools Required
2.0 Installation Overview
3.0 Before Installation - Important!
4.0 Mounting Hardware & Back Installation
5.0 ETAC Wheelchair Recline Adjustments (for greater seat depth)
1.0 Tools Required
Hex Key (5mm): (provided)
Hex Key (2mm): (provided)
Wrench (13mm)
Tape Measure/Ruler
2.0 - Installation Overview
Our ETAC Mounting Hardware has been uniquely designed to allow the mounting
of our MaTRx-PB and Matrx-PB Elite Back Cushions* onto an ETAC wheelchair. The
ETAC hardware utilizes a unique mounting clamp, specially designed to install onto the
back canes of an ETAC wheelchair. The remaining hardware utilizies the same com-
ponents as our standard easy-set mounting hardware, thereby providing clients with
the same ease of installation & adjustment they have grown accustom to.
*Important! the ETAC Mounting Hardware is not recommended for use with
our Heavy-Duty Matrx backs.
