6.0 Control options
6.1 DMX
6.1.1 Overview DMX channels P10 Profile
The P10 Profile offers 2 different channel modes. Menu PERSONALITY -> DMX MODE you can
select your mode. The used mode will be displayed in the main menu.
Mode 1 (M1)
Channel 1
Pan
Channel 2
Pan fine
Channel 3
Tilt
Channel 4
Tilt fine
Channel 5
Control channel
Channel 6
Shutter
Channel 7
Dimmer
Channel 8
Focus
Channel 9
Zoom
Channel 10
Autofocus distance
Channel 11
Reserved
Channel 12
Iris
Channel 13
Gobo 1
Channel 14
Gobo 1 rotation
Channel 15
Gobo 2
Channel 16
Gobo 2 rotation
Channel 17
Aperture 1a
Channel 18
Aperture 1b
Channel 19
Aperture 2a
Channel 20
Aperture 2b
Channel 21
Aperture 3a
Channel 22
Aperture 3b
Channel 23
Aperture 4a
Channel 24
Aperture 4b
Channel 25
Aperture rotation
Channel 26
Colour wheel
Channel 27
Cyan
Channel 28
Magenta
Channel 29
Yellow
Channel 30
CTO
Channel 31
Sparkle
Channel 32
Sparkle speed
Channel 33
Prism 1
Channel 34
Prism 1 rotation
Channel 35
Frost 1
Channel 36
Frost 2
Channel 37
Effects macro
Channel 38
Pan/tilt speed
Channel 39
Effect speed
Channel 40
Blackout Move
- 22 -
Mode 2 (M2)
Pan
Pan fine
Tilt
Tilt fine
Control channel
Shutter
Dimmer
Fine dimmer
Focus
Fine focus
Zoom
Fine zoom
Autofocus distance
Reserved
Iris
Fine iris
Gobo 1
Gobo 1 rotation
Gobo 1 fine rotation
Gobo 2
Gobo 2 rotation
Gobo 2 fine rotation
Aperture 1a
Aperture 1a fine
Aperture 1b
Aperture 1b fine
Aperture 2a
Aperture 2a fine
Aperture 2b
Aperture 2b fine
Aperture 3a
Aperture 3a fine
Aperture 3b
Aperture 3b fine
Aperture 4a
Aperture 4a fine
Aperture 4b
Aperture 4b fine
Aperture rotation
Fine aperture rotation
