2.2. Ventilation of the Sauna Room › Image 3
The ventilation of the sauna room should be arranged as follows:
Gravity exhaust ventilation
A. The fresh air inlet must be placed close to the floor near the stove and
B. its outlet should be as far as possible from the stove and near the ceiling. The stove itself circulates air effectively;
the purpose of the outlet is mainly to remove moisture from the sauna after bathing.
Mechanical exhaust ventilation
A. The fresh air inlet must be approx. 500 mm above the stove and
B. the outlet should be close to the floor, for example, below the bench.
2.3. Protecting the Floor › Image 4
See Warnings and notes!
EN
2.4. Safety Distances › Image 5
See Warnings and notes!
2.5. Adjustable Legs
The adjustable legs enable the stove to be installed firmly on an inclined floor. The adjustable range is 0–30 mm.
Unscrew the adjustable feet to an extent that allows them to be adjusted using a wrench (17 mm) when the stove is in
position. The adjustable feet could scratch the floor surface if the stove is moved on the floor.
2.6. Connecting the Stove to a Masonry Flue › Images 6-10
Make an opening in the fireproof wall for the flue connection. Notice that the opening has to be at the correct height,
if you intend to use, for instance, a protective bedding. The hole should be slightly larger than the flue connecting
pipe. A suitable gap around the connection pipe is ca. 10 mm. It is advisable to round off the inner corners of the flue
opening to ensure that the combustion gases can flow freely to the flue. Additional accessories are available to make
the installation easier ( › Accessories).
Connecting the stove to a masonry flue via the rear connection opening › Images 6, 9
1. Open the cover hatches of the rear connection opening
2. Attach the flue connection pipe to the rear connection opening. Ensure that the pipe fits tightly in place.
3. Push the stove into place. Do not block the flue by pushing the flue connection pipe too far into the flue. If
necessary, shorten the pipe.
4. Seal the flue connection pipe to the opening in the fireproof wall, for example, by using fireproof mineral wool.
Make sure that the flue connection is tightly sealed. Add more fireproof mineral wool if necessary.
Connecting the stove to a masonry flue via the upper connection opening › Images 6-8, 10
You will need an angled smoke pipe (45° or 90°) for the upper connection ( › Accessories).
1. Open the cover hatches of the rear connection opening.
2. Move the blocking plug from the upper connection opening to the rear connection opening.
3. Turn the cover hatches back up and lock it in its position with a screw.
4. Attach the flue connection pipe to the upper connection opening. Ensure that the pipe fits tightly in place.
5. Push the stove in place. Do not block the flue by pushing the flue connection pipe too far into the flue. If necessary,
shorten the pipe.
6. Seal the flue connection pipe to the opening in the fireproof wall, for example, by using fireproof mineral wool.
Make sure that the flue connection is tightly sealed. Add more fireproof mineral wool if necessary.
14
