Losses and cooling data
Drive type
U = 400 V
n
ACS880-04-505A-3
ACS880-04-585A-3
ACS880-04-650A-3
ACS880-04-725A-3
ACS880-04-820A-3
ACS880-04-880A-3
U = 500 V
n
ACS880-04-460A-5
ACS880-04-503A-5
ACS880-04-583A-5
ACS880-04-635A-5
ACS880-04-715A-5
ACS880-04-820A-5
ACS880-04-880A-5
U = 690 V
n
ACS880-04-330A-7
ACS880-04-370A-7
ACS880-04-430A-7
ACS880-04-470A-7
ACS880-04-522A-7
ACS880-04-590A-7
ACS880-04-650A-7
ACS880-04-721A-7
1) Typical drive losses when it operates at 90% of the motor nominal frequency and 100% of the drive nominal output
current (calculated according to IEC61800-9-2).
Air flow
Frame size
3
m /h
R10 1200
R10 1200
R10 1200
R11 1200
R11 1200
R11 1420
R10 1200
R10 1200
R10 1200
R10 1200
R11 1200
R11 1420
R11 1420
R10 1200
R10 1200
R10 1200
R11 1200
R11 1200
R11 1200
R11 1420
R11 1420
Technical data and references 265
Heat dissipation
3
ft /min W
707 6493
707 6827
707 8067
707 8127
707 9740
848 10986
707 5795
707 6661
707 6886
707 7923
707 8126
848 9995
848 11206
707 4863
707 5785
707 7166
707 6356
707 7375
707 8851
848 8427
848 9767
1)
Noise
dB(A)
72
72
72
72
72
71
72
72
72
72
72
71
71
72
72
72
72
72
72
71
71
