Use

General

Make all vacuum manifold and electrical connections and refer to
Turbo-V pump instruction manual before to operating the Turbo-V
controller.
WARNING! To avoid injury to personnel and damage to the equipment, if the pump is laying
on a table make sure it is steady. Never operate the Turbo-V pump if the pump
inlet is not connected to the system or blanked off.
The input signal P1 connector should be left in position including the shipping
NOTE
links if no external connections are made. The forepump and the Turbo-V ICE
pump can be switched on at the same time.
When the Turbo-V 700 ICE pump is baked by a membrane pump, the Soft Start
NOTE
mode should be deselected.
