4. Installation
5. Using the Tap
Boiling water lever Boiling water lever
White filter
LED

Commissioning

1. Before using the unit for the first time, flush through the connecting pipes and hoses
thoroughly. To flush, detach the flexible hose from the water inlet of the undersink
unit and hold it over a drain or bucket. Turn on the water and allow it to run for
several minutes. Then reattach the hose to the water inlet of the undersink unit and
check the installation for leaks.
2. If no leaks are found, plug the plug into the socket and press the On switch on the
right-hand side of the undersink unit to activate the unit.
3. A prompt will appear on the display asking you to flush the filter. A container with a
capacity of about 10 litres will be needed to collect the water.
a. Open the service hatch on the front of the unit. Place the end of the plastic hose
in the collecting container and open the valve on the hose.
b. Touch 'Start' to start flushing.
c. Allow about 10 litres of water to drain out and then touch 'Stop' to stop flushing.
Close the valve on the hose and touch 'Next'.
4. Start temperature calibration, following the instructions on the display. During
this process the boiling point of water will be determined and the boiling water
temperature will be set accordingly. Calibration takes five to ten minutes. During
this time the red lever will flash and steam may discharge from the tap.
5. The unit will then be in normal operating mode. Wait for the red lever to show a
steady light, and then check the water flow and the temperature.
6. Register the appliance with the customer service department online at
www.clage.com.
Note: If the drinking water system has not been used for several days, allow the
tap to run water for about five minutes.
Operation
Classic
Press the red lever to dispense boiling water. Pull the lever up to dispense boiling
water continually. The water will flow for 5 to 15 seconds. This time can be set in the
menu. The lever then has to be manually returned to the Off position.
Arc
Turn the lever to dispense water. When the lever is turned back, water will flow as
long as the lever is held. If the lever is turned forwards, water will flow continually for
SELECT
5 to 15 seconds. This time can be set in the menu. The lever then has to be manually
SAFETY
returned to the Off position.
Red light
• On all the time: boiling water is ready and can be dispensed.
• Flashing: the water has not yet been heated to the set temperature.
White filter LED (Classic)
• Flashing: the filter needs to be replaced. This LED starts flashing according to filter
use and the filter capacity set in the menu.
Note: For the tap Arc the need for a filter replacement is indicated by cyclically
flashing all the LEDs.
