Zip HydroTap ® G4 B160

2. Description of Appliance

The Zip HydroTap ® G4 B 160 is an electronically controlled system which delivers filtered boiling water for kitchens and pantries. The
appliance itself is stowed away out of sight below the sink and the water is dispensed via a special tap. The Classic and Arc tap can
be positioned alongside the kitchen tap or separately with a flat draining tray, as desired.
EN

3. Technical Data

Model
Rated voltage / rated power
Rated pressure
Hot water temperature range
Hot water tank volume
Water connection
Size (H × W × D)
Weight (filled)
Ambient temperature
Protection class according to VDE
Type of protection
1) Connecting hose G ½" with supplied adapter G ⅜"
ARC
MPa / bar
Classic
°C
litres
cm
kg
°C
18
Zip HydroTap ® G4 B 160
Zip HydroTap ® G4 B 160
230 V AC / 1.9 kW
0.17 – 0.70 / 1.7 – 7.0
68 – 100
3.0
G ½" or G ⅜" 1)
33.5 × 28.0 × 31.3
12
5 – 35
Klasse I
IP20
