Zip HydroTap ® G4 B160

5. Using the Tap

EN
SELECT
SAFETY

Child safety lock

Classic
A child safety lock can be enabled to prevent boiling water flowing out of the tap if the
red lever is accidentally operated. To dispense boiling water when the child safety lock
is enabled, press the Safety button and the red lever at the same time.
The child safety lock can be enabled and disabled under Settings/Safety in the menu.
Arc
To dispense boiling water when the child safety lock is enabled, double-tap the safety
button twice in quick succession. The red LEDs start to flash and boiling water can be
dispensed by turning the lever. After 3 seconds without operation, the LEDs light up
continuously and the tap is locked again.
The child safety lock can only be activated and deactivated in the menu when using the
Arc.
Safety button

Menu

The undersink unit has a touch screen which can be used to set and read the operating
parameters. The following settings can be carried out in the menu:
'Language'
Select the language used in the menu.
'Information'
Shows data specific to the unit and any errors occurring.
'Install'
The steps that are necessary when using the unit for the first time can be viewed again
for maintenance purposes.
Flush filter – place the end of the hose located at the filter in a collecting container and
open the isolating valve on the hose before starting to flush the filter.
Reset filter – resets the filter consumption data.
Boiling point calibration – the unit determines the boiling point, which depends on the
atmospheric pressure at the installation location, and adjusts accordingly.
Booster – settings for operation of an additional instantaneous water heater to
preheat the hot water. A technical modification has to be made to the unit in order to
connect up a booster (not included in CLAGE range).
Light sensor calibration – the light sensor on the Classic tap can be calibrated for the
light conditions at the installation location. This is necessary to ensure that the Sleep
mode energy-saving function operates correctly. Shield the tap from direct sunlight
during calibration.
'Service'
A special password specific to the unit is needed in order to access the Service menu.
Please contact Central Customer Service.
'Password'
A user password can optionally be set to lock the 'Settings' menu and prevent
unauthorised persons from altering the settings. The password should be 4 digits long.
'Radio'
N/A.
'Settings'
Date/time – set the time and the time format.
Temperature – set the water temperatures.
24
