Single DC (48-57VDC) Input
1. Insert positive/negative DC power wires into Contacts 1 and 2 for PWR1.
2. Tighten the wire-clamp screws for preventing the wires from loosening.
Dual Redundant DC (48-57VDC) Input
1. Insert positive/negative DC power wires into Contacts 1 and 2 for PWR1 and Contacts 5 and 4 for
PWR2.
2. Tighten the wire-clamp screws for preventing the wires from loosening.
8
Description
Positive
Negative
Requiring good ground connection
1
2
V1+
V1-
PWR1
1
2
V1+
V1-
PWR1
3
4
5
V2-
V2+
PWR2
3
4
5
V2-
V2+
PWR2
