6. Check that the workpiece is securely seated.
» The workpiece is now clamped.
7.2. REMOVING THE WORKPIECE
1. Before removal of the workpiece, clean the vacuum plate under vacuum using an
industrial vacuum cleaner.
Fault
Operating vacuum not achieved or is too
low, and the compressed air unit is running
Vacuum plate changed over to vacuum
connection: Operating vacuum not
achieved or is too low, and the vacuum
pump is running
The clamping face of the vacuum plate is
damaged
The restraining force is insufficient to ma-
chine the workpiece
10. Cleaning
Clean with a cloth or compressed air.
Do not use any corrosive cleaning agent.
11. Storage
Store in an enclosed dry room.
Do not store close to corrosive or aggressive chemical substances, solvents, moisture
or dirt.
Protect against direct sunlight.
Store at temperatures between +15° C and +35 °C.
Relative atmospheric humidity max. 60%
12. Spare parts
Use only original spare parts and wearing parts.
Use only a Ø 4 mm sealing cord.
13. Disposal
Comply with the national and regional environmental protection and disposal regu-
lations for correct disposal or recycling. Segregate items into metals, non-metals,
composite materials and consumables and dispose of them responsibly.

14. Technical data

Article no. / type
Length
Width
Height
Grid
Operating medium
Permissible operating pressure
Operating pressure for maximum vacuum
Maximum vacuum
Ambient temperature
Operating medium temperature
Compressed air hose
or hose coupling adaptor
Possible cause
Leaky compressed air hoses
Dirt between the workpiece and vacuum
plate
Seal defective or not fitted
Kink in the compressed air hoses
Shut-off valve not fully turned on.
Leaky vacuum hoses
Dirt between the workpiece and vacuum
plate
Seal defective or not fitted
Kink in the vacuum hoses
Defective machining of the workpiece
Clamping area is too small
Diameter of the vacuum hoses too small, or
vacuum hoses too long
Power of the vacuum pump insufficient
384900 / VRV0
200 mm
125 mm
21 mm
12.5 mm
Compressed air to ISO
8573-1:2010 [7:4:4]
not oiled
max. 7.0 bar
4.0 bar
91% (approx. 93 mbar at stand-
ard pressure)
0 °C - 60 °C
0 °C - 60 °C
Ø 10 mm
7.2 mm
2. After cleaning away all debris and chips, switch off the operating vacuum.
3. Remove the workpiece.
8. Maintenance
The vacuum plate is maintenance-free.
9. Faults and troubleshooting
Action
Exchange the compressed air hoses
Clean the faces of the workpiece and va-
cuum plate
Change the seal
Align the compressed air hoses correctly
Turn the shut-off valve fully on
Change the vacuum hoses
Clean the faces of the workpiece and va-
cuum plate
Change the seal
Align the vacuum hoses correctly
Check the machining program
Increase the clamping area
Use additional restraints for workpiece
Increase the diameter of the vacuum hoses,
or reduce the length of the vacuum hoses
Increase the power of the vacuum pump
Performed by
Trained specialist for mechanical work
Trained person
Trained specialist for mechanical work
Trained person
Trained specialist for mechanical work
Trained specialist for mechanical work
