Maintenance - Scheppach MS150-42E SE Original Bedienungsanleitung

• Slowly pull back the starter handle, which will bathe
in the cylinder wall with oil.
• Screw the spark plug back in.
• Clean the cooling fins of the cylinder and the housing.
• Be sure to clean the entire machine to protect the
paint.
• Store the machine in a well-ventilated place.
Battery Pack and Charger
• When not in use, disconnect charger and store in a
cool, dry area. Wet, damp areas can cause corro-
sion of terminals and electrical contacts. If stored for
long periods in high temperatures (120° F / 49° C),
permanent damage to the battery pack can result.
Check electrical terminals and contacts on battery
packs and charger. Wipe with clean cloth or blow
clean with compressed air.
• After storage, a normal charge may be required.
To check available charge, press the Battery Fuel
Gauge button (E, Figure 24) and charge if required.
See the Battery Fuel Gauge section.

13. Maintenance

• Regular, careful maintenance is required to guaran-
tee the safety level and performance of the machine.
• Make sure that all nuts, bolts and screws are tight-
ened securely and that the machine is in safe work-
ing condition.
• Routinely check the grass basket for signs of wear
and impaired functionality.
Regularly clean the grass box with water and let it
dry thoroughly.
• For your own safety, replace worn or damaged parts
without delay.
• If the fuel tank should require emptying this should
only be done in the open air using a petrol suction
pump (available from DIY shops).
m WARNING
Never work on or touch conducting parts on the ignition
unit with the engine running. Always pull the spark plug
boot from the spark plug before starting any work of
care or maintenance. Never perform any work on the
machine while it is running. Any work not described in
these Operating Instructions must be performed by an
authorized service workshop only.
m Attention!
Always shut the engine down and remove the spark
plug connector before carrying out any cleaning work.
Wheel axles and wheel hubs
• These should be lightly greased once a season.
Blade
For safety reasons you should only ever have your blade
sharpened, balanced and mounted by an authorized
service workshop. For optimum results it is recommend-
ed that the blade should be inspected once a year.
Only ever use original spare parts when having the
blade replaced.
Wear gloves when replacing the blade in order to pre-
vent injury.
Never have any other blade fitted.
• Empty the fuel tank before removing the blade
• To replace the blade, undo the screw.
• Reinstall as illustrated in Fig. 17. Tighten the screw
properly. Tightening torque 45 Nm. When replacing
the blade, the blade screw should also be replaced.
Damaged blades
Should the blade, in spite of all precautions, come into
contact with an obstruction, shut down the engine im-
mediately and pull the spark plug boot. Tip the lawn
mower onto its side and check the blade for damage.
Damaged or bent blades must be replaced. Never at-
tempt to bend a bent blade back to straight again. Nev-
er mow the lawn with a bent or heavily worn blade as
this will cause vibrations and can lead to further dam-
age to the lawn mower.
m CAUTION! There is a risk of injury if you work with
a damaged blade.
Resharpening the blade
The blades can be resharpened with a metal file. In
order to avoid imbalance, the blade should be resharp-
ened by an authorized service workshop
Checking the oil level
m CAUTION! Never run the engine with no or too little
oil. This could cause severe damage to the engine. Use
only SAE30 engine oil.
Checking the oil level (Fig. 18):
• Stand the lawn mower on a flat level surface.
• Unscrew the oil dip stick (12) by turning anticlockwise,
pull out and wipe. Insert the dip stick back in the filling
mount as far as the stop, but do not screw back in.
• Pull out the dip stick (12) again and read off the oil
level while holding horizontally. The oil level must be
between the maximum and the minimum
www.scheppach.com GB | 43
