12. Storage

• Never store the mower (with petrol in the tank) in-
side a building in which petrol fumes could come
into contact with open flames or sparks.
• Allow the motor to cool before you put the lawn
mower in an enclosed area.
• In order to avoid fire hazards, keep the engine, ex-
haust and the area around the fuel tank free from
grass, leaves and leaking grease (oil).
Preparing the mower for long-term storage
Caution: Do not empty the petrol tank in enclosed
areas, near fire or when smoking. Petrol fumes can
cause explosions and fire.
• Empty the petrol tank with a petrol suction pump.
• Start the engine and let it run until any remaining
petrol has been used up.
• Change the oil at the end of every season. To do
so, remove the used engine oil from a warm engine
and refill with fresh oil.
• Remove the spark plug from the cylinder head.
• Fill the cylinder with approx. 20 ml of oil from an
oil can.
• Slowly pull back the starter handle, which will bathe
the cylinder wall with oil. Screw the spark plug back in.
• Clean the cooling fins of the cylinder and the hous-
ing.
• Be sure to clean the entire machine to protect the
paint.
• Store the machine in a well-ventilated place.

13. Maintenance

• Regular, careful maintenance is required to guaran-
tee the safety level and performance of the machine.
• Make sure that all nuts, bolts and screws are tight-
ened securely and that the machine is in safe work-
ing condition.
• Routinely check the grass basket for signs of wear
and impaired functionality.
Regularly clean the grass box with water and let it
dry thoroughly.
• For your own safety, replace worn or damaged
parts without delay.
• If the fuel tank should require emptying this should
only be done in the open air using a petrol suction
pump (available from DIY shops).
m WARNING
Never work on or touch conducting parts on the ig-
nition unit with the engine running. Always pull the
spark plug boot from the spark plug before starting
any work of care or maintenance. Never perform any
work on the machine while it is running. Any work not
described in these Operating Instructions must be
performed by an authorized service workshop only.
Wheel axles and wheel hubs
• These should be lightly greased once a season.
Blade
For safety reasons you should only ever have your
blade sharpened, balanced and mounted by an au-
thorized service workshop. For optimum results it is
recommended that the blade should be inspected
once a year.
Changing the blade (Fig. 17)
Only ever use original spare parts when having the
blade replaced.
Wear gloves when replacing the blade in order to pre-
vent injury.
Never have any other blade fitted.
• Empty the fuel tank before removing the blade
• To replace the blade, undo the screw.
• Reinstall as illustrated in Fig. 17. Tighten the screw
properly. Tightening torque 45 Nm. When replacing
the blade, the blade screw should also be replaced.
Damaged blades
Should the blade, in spite of all precautions, come
into contact with an obstruction, shut down the en-
gine immediately and pull the spark plug boot. Tip
the lawn mower onto its side and check the blade for
damage. Damaged or bent blades must be replaced.
Never attempt to bend a bent blade back to straight
again. Never mow the lawn with a bent or heavily
worn blade as this will cause vibrations and can lead
to further damage to the lawn mower.
m CAUTION! There is a risk of injury if you work with
a damaged blade.
Resharpening the blade
The blades can be resharpened with a metal file. In
order to avoid imbalance, the blade should be re-
sharpened by an authorized service workshop
Checking the oil level
m CAUTION! Never run the engine with no or too lit-
tle oil. This could cause severe damage to the engine.
Use only SAE30 engine oil.
Checking the oil level (Fig. 18):
• Stand the lawn mower on a flat level surface.
• Unscrew the oil dip stick (12) by turning anticlock-
wise, pull out and wipe. Insert the dip stick back in
the filling mount as far as the stop, but do not screw
back in.
• Pull out the dip stick (12) again and read off the
oil level while holding horizontally. The oil level
must be between the maximum and the minimum
Changing the oil Fig. 23
• Change the engine oil every year before the start of
the season when the engine is warm.
• Use only engine oil (SAE30).
• Empty the fuel tank (with a petrol suction pump)
• Place a flat oil drip tray in front of the mower (min.
volume 1 Litre).
• Remove the dipstick and tip over the mower until
the whole oil is run out into the oil drip tray.
