HBK MP60 Bedienungsanleitung Seite 84

Information
The MP60 can indicate transducer errors generated by the torque sensor. But to do this,
the error signal from the torque sensor must be connected across pin 7 of the transducer
plugs (15-pin sub-D plugs).
The "transducer error" function in the MP60 must also be activated.
Operating state and LED signaling
LED State
color
Green Steady
light
Green Flashing
Steady
Yellow
light
LED State
color
Red Flashing
Red Steady
light
82
Measuring mode
Ready for measurement
Data being transferred over the
interface
Ready for measurement
Measuring mode
Measured value
overflow
LCD error
Initialization phase:
Not (yet) ready for
measurement,
calibration error
Initial calibration error
Meaning
CAN Operational (PDO transfer
(PDO transfer not possible)
Meaning
Bus mode
CAN Transmit error
CAN bus not ready to
communicate
(bus OFF)
ERROR MESSAGES/OPERATING STATE (LED)
Bus mode
possible)
-
CAN bus PreOperational
Remedy
Adapt
measuring
range
Restart
Send the PME
to the manufac­
turer (HBM)
MP60, MP60DP
Wait
