Connection with the mains

Connect the device to the mains with the enclosed power supply cable.
The occupation of the connection-cables is as follows:
Cable Pin
Brown Live
Blue Neutral
Yellow/Green Earth
The earth has to be connected!
If the device will be directly connected with the local power supply network, a disconnection switch with a
minimum opening of 3 mm at every pole has to be included in the permanent electrical installation.
The device must only be connected with an electric installation carried out in compliance with the IEC-
standards. The electric installation must be equipped with a Residual Current Device (RCD) with a maximum
fault current of 30 mA.
Lighting effects must not be connected to dimming-packs.
The device is equipped with a lockable power input connector. Plug in the power cord and turn it to the right
until it locks. Plug the power cord into a grounded electrical outlet that matches the rated voltage of the
machine.

Connection between devices

On the rear panel, there is a socket (Power Out). Connect the output with the mains input of the next fixture
until all fixtures are connected.
Please note: A maximum of 8 devices may be linked together. After every 8 devices,
the fixtures must have a renewed connection with the power mains.

OPERATION

After you connected the spot to the mains, the FUTURELIGHT POS-8 LED HCL Powerstick starts running.
The display lights up and you can choose the desired mode via the buttons MODE, ENTER, UP and DOWN.

Stand-alone mode

In the stand-alone mode, the FUTURELIGHT POS-8 LED HCL Powerstick can be used without controller.
Disconnect the FUTURELIGHT POS-8 LED HCL Powerstick from the controller. Please refer to the
instructions under chapter Control Board.

Master/Slave-operation

The master/slave-operation enables, that several devices can be synchronized and controlled by one
master-device.
On the rear panel of the POS-8 LED HCL Powerstick you can find an XLR-jack (DMX Out) and an XLR-plug
(DMX In), which can be used for connecting several devices.
Choose the device which is to control the effects. This device then works as master device and controls all
other slave devices, which are to be connected to the master device via a DMX cable. Connect the DMX
OUT jack with the DMX IN plug of the next device.
Set the desired master-mode for the master-device and the slave-mode for all slave-devices. Please refer to
the instructions under chapter Control Board.
International
L
N
