DESCRIPTION OF THE DEVICE
Features
LED color changing bar with 10 W HCLs
•Equipped with 8 hexacolor LEDs in the colors red, green, blue, amber, white and purple
•HSV, HSI, 6, 8, 12, 48 or 53 DMX channels selectable
•Each LED can be controlled individually
•Suitable for pixel mapping applications
•Flicker-free projection
•Hanging as well as standing installation possible
•Functions: Static colors RGBAWP color mixture, color presets, preset color temperatures, automatic color
change, built-in programs, dimmer, strobe effect, sound-control, Master/Slave operation
•Dimmer speed (step response) adjustable
•Sound-controlled via built-in microphone
•Adjustable microphone sensitivity
•DMX-controlled operation or stand-alone operation with Master/Slave function
•Comfortable addressing and setting via Control Board with LC display and four operating buttons
•Switch-mode power supply for operation between 100 and 240 Volts
•Power connection via Neutrik PowerCon jack and included power cable
•Feed-through output allows to power up to 8 devices
•DMX control via every standard DMX controller
Overview
1
9
10
11
12
13
2
3
4
14
18
15
16
17
(1) Venting slots
(2) Housing screw
(3) Fixation screw
(4) Mounting bracket
(5) LED
(6) Housing
(7) Floor-stand
5
6
7
8
(8) Fixation screw
(9) 3-pin DMX input
(10) 3-pin DMX output
(11) 5-pin DMX input
(12) 5-pin DMX output
(13) Mode button
(14) Enter button
(15) Display
(16) Up button
19
20
21
(17) Down button
(18) Microphone
(19) Power input
(20) Power output
(21) Fuseholder
25/38
mounting bracket
floor-stand
00080641, Version 1.0
