11.2 Troubleshooting

Fault Fault text
no.
1 Minimum pressure alarm
2 Maximum pressure alarm Upper alarm limit for pressure
5 Supply flow too low
6 Pressure increasing
volume
7 Pressure increasing time
8 Valve is defective
10 Cycle interval
11 Number of cycles
12 Limitation of quantities
13 Limitation of runtime
14 Filling volume exceeded
15 Filling time exceeded
16 Replace module
17 Sensor voltage
18 Pressure sensor, short-
circuit
19 Pressure sensor, cable
fracture
20 No date/time
25 Scheduled maintenance
date
Description of the message Reasons for fault
Lower alarm limit for pressure Leakage; supply pressure too low;
underrun pressurisation incorrectly set
Solenoid valve does not close / is defective;
overrun pSV set too low; pressurisation system
defective
IWZ does not supply any signal Supply flow too low; IWZ not connected
after replenishment request
During the specified Solenoid valve does not open; water supply
replenishment quantity the insufficient; setting incorrect
pressure has not increased by at
least 0.1 bar
During the specified Solenoid valve does not open; water supply
replenishment time the insufficient; setting incorrect
pressure has not increased by at
least 0.1 bar
Replenishment without request Solenoid valve does not close; pulses on
water meter with valve closed
Minimum replenishment cycle Pause times are underrun by the system;
interval underrun leakage
The maximum number of cycles Too frequent replenishment request within a
within a window has been running time window; leakage
exceeded
The maximum quantity of a Leakage in the system
replenishment cycle has been
exceeded
The maximum time for a Leakage in the system
replenishment cycle has been
exceeded
Maximum volume of initial System still insufficiently filled; leakage
filling has been exceeded
Maximum time of initial filling System still insufficiently filled; leakage
has been exceeded
Treatment quantity for water Module capacity used up
treatment module has been
exceeded
Minimum sensor voltage Board is defective
underrun
Short-circuit in current loop of Short-circuit
pressure sensor
Interruption of pressure sensor Cable fracture
current loop
RTC does not have any valid Time not entered during commissioning
time information
Scheduled maintenance date Scheduled maintenance date reached
reached
We reserve the right to change designs and technical specifications of our products.
Fault removal
Repair leakage; increase
supply pressure; set
pressurisation correctly
Replace solenoid valve;
correct pSV setting; e.g.
correct MAG primary
pressure
Connect IWZ; increase
supply pressure
Increase supply quantity; if
necessary, increase setting;
check solenoid valve
switching process
Increase supply quantity; if
necessary, increase setting;
check solenoid valve
switching process
Replace or clean solenoid
valve
Repair leakage; if necessary,
correct setting
Repair leakage; if necessary,
correct setting
Repair leakage; if necessary,
correct setting
Repair leakage; if necessary,
correct setting
Reactivate filling mode; if
necessary, correct setting;
repair leakage
Reactivate filling mode; if
necessary, correct setting;
repair leakage
Replace module
Replace control unit
Check seating/connection
of the cables; change cable
Check seating/connection
of the cables; change cable
Set time when
commissioning (parameter
menu)
Carry out maintenance
