40 | English
Combination saw
Laser type
Laser class
Weight according to EPTA-Procedure 01:2014
Protection class
Dimensions of suitable saw blades
Saw blade diameter
Base blade thickness
Max. cutting width
Hole diameter
The specifications apply to a rated voltage [U] of 230 V. These specifications may vary at different voltages and in country-
specific models.
Permissible workpiece dimensions (maximum/minimum) mitre saw: (see "Permissible workpiece dimensions", page 44)
Permissible workpiece dimensions (maximum/minimum) table saw: (see "Setting the Saw Blade Height (see figure
page 46)
Values can vary depending upon the product and are subject to application and environmental conditions. For further informa-
tion www.bosch-professional.com/wac.

Noise Information

Noise emission values determined according to
EN 61029-2-11.
Typically, the A-weighted noise level of the power tool is:
Sound pressure level 91 dB(A); sound power
level 104 dB(A). Uncertainty K = 3 dB.
Wear hearing protection!
The noise emission value given in these instructions has
been measured in accordance with a standardised measur-
ing procedure and may be used to compare power tools. It
may also be used for a preliminary estimation of noise emis-
sions.
The noise emission value given represents the main applica-
tions of the power tool. However, if the power tool is used
for other applications, with different application tools or is
poorly maintained, the noise emission value may differ. This
may significantly increase noise emissions over the total
working period.
To estimate noise emissions accurately, the times when the
tool is switched off, or when it is running but not actually be-
ing used, should also be taken into account. This may signi-
ficantly reduce noise emissions over the total working
period.
Assembly and Transport
Avoid starting the power tool unintentionally. The
u
mains plug must not be connected to the power supply
during assembly or when carrying out any kind of
work on the power tool.

Items Included

– Carefully remove all parts included in the delivery from
their packaging.
1 609 92A 7SS | (06.03.2023)
GTM 12 JL
nm 650
mW
kg 21.1
mm 300–305
mm 1.5–2.0
mm
mm
– Remove all packing material from the power tool and the
accessories provided.
Check to ensure that all the parts listed below have been
supplied before using the power tool for the first time:
– Combination saw with pre-mounted saw blade
– Hex key/slotted screwdriver (5)
– Dust bag (8)
additionally for table saw:
– Parallel guide (61)
– Push stick(62)
– Lower saw blade cover (66)
Note: Check the power tool for possible damage.
Before continuing to use the power tool, carefully check that
all protective devices or slightly damaged parts are working
perfectly and according to specifications. Check that the
moving parts are working perfectly and without jamming;
check whether any parts are damaged. All parts must be fit-
ted correctly and all the conditions necessary to ensure
smooth operation must be met.
If the protective devices or any parts become damaged, you
must have them properly repaired or replaced by an author-
ised service centre.
Stationary or Flexible Assembly
To ensure safe handling, the power tool must be
u
mounted on a flat, stable work surface (e.g. work
bench) before use.
Assembly on a Work Surface (see figures a−b)
– Use a suitable screwed connection to secure the power
tool to the work surface. The holes (3) are used for this
purpose.
or
GTM 12 JL
650
< 1 < 1
2 2
21.1
/ II / II
300–305
1.5–2.0
3.0 3.0
30 30
B)",
